ULTRABEAM Chevron 12-Grid A, 2.8 x 3.3 m, lit on the ceiling of a 6 x 6 m double garage
ULTRABEAM LED Light Kit Chevron 12-Grid A, Blue border: its size, measured
Chevron 12-Grid A
3.4 x 2.9 m

ULTRABEAM™ LED Light Kit Chevron 12-Grid A

3.4 x 2.9 m

$1,829 $2,299 Save $470

Taxes included. Shipping calculated at checkout.

Quantity
1
In stock in Melbourne, ready to shipCertified for Australia 5-year warranty

About the Chevron 12-Grid A light kit

3.4 x 2.9 mSize
101Tubes
57,420Lumens
638 WWatts
1Power point
DaylightColour, 6500K

$1,829Chevron 12-Grid A, 3.4 x 2.9 m

Before you order

This kit is 3.3 x 2.8 m. Measure the ceiling you want lit and pick the size that fits inside it.

Even light with no hard shadows, because it comes from the whole grid. 57,420 lumens of 6500K daylight from 87 tubes.

Lay it out on the floor, click the tubes into the connectors and test it. Then lift it and fix it to the ceiling. An afternoon with a helper.

Into a standard power point, with one 1.5 m cord for the whole kit. A border has its own cord, so it needs a second socket. To put it on a wall switch, use a licensed electrician.

87 tubes, the connectors, hanging cables, fixings and the power cord. The kit ships complete.

What arrives

Everything to hang it, in one box.

101 tubes, the connectors, hanging cables, fixings and 2 power cords, 1.5 m each. A cord for the light and one for the border.

  • ULTRABEAM™ TubesTubes
  • ULTRABEAM™ ConnectorsConnectors
  • ULTRABEAM™ Power cordPower cord
  • ULTRABEAM™ Hanging cablesHanging cables

How it goes up

Up in an afternoon.

A drill, a screwdriver, a ladder and a power point to plug it into.

  1. 1Lay it outOn the garage floor, the way it will hang.
  2. 2Click it togetherEach tube pushes into its connector.
  3. 3Test itPlug it in on the floor and check every tube lights.
  4. 4Hang itLift it with a helper and fix it flush or on its cables.

Twelve chevrons stacked through 3.3 metres of premium V-pattern.

A premium tall chevron layout, 87 tubes carrying 57,000 lumens of true daylight across 9 square metres. Twelve V's climbing the column, the directional flow holding from the front of the room to the back.

Why it works

  • Tall premium flow. 87 tubes form twelve chevrons through 3.3 metres of column — directional V-rhythm at scale.
  • True colours. CRI 85+ daylight white shows your paint, your finish, your work as it really looks.
  • Plug and play. Standard AU 3-pin earthed outlet, no hardwiring. To put it on a wall switch, use a licensed electrician.
  • A couple of hours to install. Lay it flat, click the tubes into the connectors, lift to the ceiling, mount, plug in. Digital install instructions sent on order.
  • Spare parts on hand. Replacement tubes, connectors and the power cord are stocked individually. If a part ever needs replacing in years to come, order the exact match.
  • Optional border. Frame your array with a perimeter of Cool Daylight, Blue or Red tubes. Adds visual edge and extra brightness.
  • All configurations designed in Australia. Layout, kit composition and customer support handled in-country.
  • Built to last. Aircraft-grade aluminium frame, sealed PC lens. 50,000 hour LEDs, 5-year warranty.
  • Safe and certified. RCM marked. EMC tested against AS/NZS safety standards.

In the box (baseline, no border)

  • 87 × LED tubes (443mm, 6500K daylight, 6W each)
  • All required connectors and suspension cables
  • Mounting hardware
  • 1.5 metre AU 3-pin earthed power cord with adapter

Per-variant totals in the Specifications tab below.

Specifications

Dimensions2.9m × 3.37m
Coverage area9.79 m²
LED tube count101
Total power638 W
Total lumens57,420 lm
Hex cells12

Electrical

Voltage100–240V AC
Colour temperature6500K daylight
CRI85+ (true colour rendering)
EfficacyAbout 110 lumens a watt
Lifetime50,000 hours
EnergyAbout 60% less power than equivalent fluorescent strips
DriverPer-tube driver

Build

Kit layouts designedAustralia
FrameAluminium
LensSealed PC, impact-resistant
ConnectorsProprietary angled, sealed mating
PlugAS/NZS 3112 3-pin earthed, 1.5m flex

Compliance

RCM markYes
EMC testedAS/NZS CISPR 15, 61547, 61000.3.2, 61000.3.3
Warranty5 years

Installation

TimeAn hour or two with a helper
ToolsDrill, screwdriver, ladder
ElectricianNot to plug in. A wall switch needs a licensed electrician.
MethodLay flat, click tubes into connectors, lift to ceiling, mount, plug in
MountingFlush mount or 1m suspension cables (included)
